Danfoss VLT FC-102P18KT4E55H3 HVAC Drive 18.5kW LOT 2

Name: Danfoss VLT FC-102P18KT4E55H3 HVAC Drive 18.5kW LOT 2
Brand: Danfoss
SKU: 2540
Price: 855.00 UAH
Availability: OutOfStock
Rating: 5 (10 reviews)

Condition: Used
Brand: Danfoss
Product Code: FC-102P18KT4E55H3XGX
SKU: #G1362#
Availability: 1
Warranty term: 30 днів
Located in: Ukraine

️ 1

0 reviews / Write a review

Price: $855.00
Ex Tax: $855.00

Description
Reviews (0)

FC-102P18KT4E55H3XGX1XXSXXXXAXBXCXXXXDX

131B7040

Frequency Converter
FC-102P18KT4E55H3XGX1XXSXXXXAXBXCXXXXDX

VLT® HVAC Drive FC-102
(P18K) 18.5 KW / 25 HP,
Three phase, 380 - 480 VAC, IP55 / Type 12
(H3) RFI Class A1/B (C1)
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB, Mains Disconnect
Latest release std. SW.
Frame: B1
No A Option, No B Option
No C1 option, No D option

Other options according to Model Code

Model code:FC-102P18KT4E55H3XGX1XXSXXXXAXBXCXXXXDX

Danfoss VLT® HVAC Drive FC-102 Drive is dedicated to ventilation, heating, and refrigeration applications. With a wide range of powerful standard and optional features, the Drive provides the lowest overall cost of ownership.

On this page you will find the user manual for Danfoss VLT FC-102. Get detailed technical specifications, installation and operating instructions to ensure optimum performance and reliability.
