The SUBCON 9/M‑SH is a rugged, 9-position male D‑SUB bus connector with screw‑terminal internal wiring. It's designed for easy field assembly and universal system compatibility. It features a 35° cable outlet, metallized housing, and knurled fastening screws.

 Key Features

• Universal compatibility for protocols like RS‑232, RS‑422, RS‑485, Modbus, INTERBUS.

• EMC‑shielded housing (metal‑plated ABS) for interference protection.

• 35° cable outlet with reversible internal block—you can rotate wiring orientation in the field.

• Field‑friendly assembly with captive knurled screws; fully 1:1 screw‑terminal assignment (each D‑SUB pin to its own terminal).

⚙️ Electrical & Mechanical Specs

 Reliability & Approvals

• MTTF (SN 29500): 6,706 years at 25 °C / 1,817 years at 40 °C / 155 years continuous 40 °C operation

• Certified: ATEX, UL/cUL/CSA, EAC, cULus

• Compliant: RoHS, IP20 enclosure standard

• Origin: Manufactured in Germany

 Advantages

• Quick, tool‑free cable assembly: just strip wires and tighten screws.

• High EMC protection for clean signal integrity.

• Reversible cable entry orientation simplifies installation in tight spaces.

• Universal pin mapping—suitable across multiple bus systems and devices.

 Applications

Ideal for industrial automation, fieldbus, communication lines (RS-232/422/485), data acquisition modules, and any application requiring reliable, maintainable connector solutions in harsh environments.

✅ Summary

The Phoenix Contact SUBCON 9/M‑SH is a durable, field‑serviceable DB9 connector with internal screw‑terminal wiring, EMC protection, and robust mechanical design. It's perfect for industrial data and communication applications needing reliable, maintenance-friendly connectors.
