Robatech Glue Jetting Head SX 1N 148511

Robatech Glue Jetting Head SX 1N (P/N 148511)

Product Description: High-quality, original hot melt glue jetting head manufactured by the Swiss company Robatech (Diamond series). Designed for precise, non-contact application of thermoplastic hot melt adhesive at high speeds. This module features enhanced durability, energy efficiency, and ensures flawless accuracy in forming glue dots and lines. The unit comes complete with an integrated original filter and an electromagnetic control valve.

Specifications:

• Manufacturer: Robatech (Switzerland)

• Head Type: Jetting Head SX 1N / 296 Diamond

• Part Number (P/N): 148511

• Serial Number (S/N): 1103673-010 / 1103673-014

• Operating Voltage (Head): 230 V, 50/60 Hz

• Heating Element Power: 110 W

• Solenoid Valve: Robatech P/N 167270 (24 VDC, 8 W power, IP65 protection rating, operating air pressure 2–6 bar / 30–90 psi)

• Built-in Filter: Filter AX, SX, SpeedStar mesh mounted (125 µm), Article No. (Art. No.): 130957

• Year of Manufacture: 2015

Application: Used in automated industrial lines for packaging and product assembly. Main applications include cardboard box gluing, tray forming, paper bag production, labeling, as well as in the printing and woodworking industries where high-speed, economical hot melt adhesive application is required.
