Siemens 3VL2716-1AA46-0AA0 + 3VL9300-3MQ00 + FR 3VL9210-6BH40 + VL160N

General Description of the Kit: This kit represents a Siemens 3VL series automatic circuit breaker system with additional accessories and components for industrial applications.

Main Components:

1. Siemens 3VL2716-1AA46-0AA0

Main Circuit Breaker:

• Series: 3VL MCCB (Molded Case Circuit Breaker)
• Rated Current: 160 A
• Rated Voltage: 690 V AC
• Number of Poles: 3-pole
• Breaking Capacity: High (exact value depends on specific modification)
• Trip Unit Type: Electronic trip unit

2. Siemens 3VL9300-3MQ00

Additional Accessory:

• Type: Auxiliary contact or signal contact
• Purpose: Indication of breaker status (on/off)
• Contact Configuration: Combined contacts (NO+NC)

3. Siemens 3VL9210-6BH40 (FR)

Trip Release:

• Type: Independent trip release (shunt release)
• Operating Voltage: 24 V DC (assumed value)
• Purpose: Remote tripping of the circuit breaker

4. VL160N

Additional Component:

• Mechanical position indicator or additional accessory for indication

Technical Specifications of the Kit:

• Application: Industrial electrical panels and distribution devices
• Protection Class: Complies with IEC standards
• Mounting: On DIN rail or in electrical panel
• Operating Temperature: -20°C to +70°C (typically)

Features and Benefits:

• High reliability and durability
• Electronic protection against overloads and short circuits
• Remote control capability
• Circuit breaker status indication
• Easy integration into automation systems
• Compliance with international safety standards

Applications:

• Industrial electrical panels
• Distribution devices
• Motor control systems
• Protection of electrical circuits in industry
• Automated control systems

This kit provides complete protection and control of electrical circuits with remote monitoring and status indication capabilities.
