Siemens SINAMICS S120 6SL3130-7TE25-5AA3 ACTIVE LINE MODULE

Siemens SINAMICS S120 Active Line Module 6SL3130-7TE25-5AA3

• Input Voltage: 3AC 380-480V, 50/60 Hz
• Output (DC Link): DC 600V, 92A
• Power Rating: 55 kW (Infeed and Regenerative)

Siemens SINAMICS S120 Active Line Module, 55 kW (6SL3130-7TE25-5AA3)

The Siemens SINAMICS S120 Active Line Module (6SL3130-7TE25-5AA3) is a high-performance, regenerative infeed unit designed for the modular SINAMICS S120 drive system. Unlike basic infeed units, the Active Line Module is self-commutated, allowing it to maintain a stable DC link voltage regardless of line voltage fluctuations and to actively feed regenerative energy back into the power grid with low harmonics.

Key Features:

• Active Infeed and Regeneration: Provides bidirectional power flow, supplying energy to the DC link and regenerating braking energy back to the grid efficiently.
• Stable DC Link Voltage: Generates a regulated 600V DC link voltage, providing stable power for connected motor modules.
• Low Harmonics: Contributes to low line harmonics and can be used for reactive power compensation, improving power quality.
• Power Rating: Offers a substantial 55 kW power capacity for demanding applications.
• Voltage: Compatible with 3-phase AC input voltages from 380V to 480V.
• System Integration: Connects the SINAMICS S120 system to the AC line supply.
• Booksize Format: Features a compact Booksize construction for efficient cabinet mounting.
• Internal Air Cooling: Equipped with internal air cooling.
• DRIVE-CLiQ Interface: Includes a DRIVE-CLiQ system interface for communication within the drive system.

This Active Line Module is ideal for high-performance multi-axis applications requiring dynamic motion, precise control, and energy efficiency, such as in cranes, elevators, test stands, and production machinery.
