Turck MS1-12Ex0-R MultiSafe Isolating Switching Amplifier

Turck MS1-12Ex0-R MultiSafe Isolating Switching Amplifier

Product Description: The Turck MS1-12Ex0-R is a single-channel isolating switching amplifier from the MultiSafe series, engineered to establish intrinsically safe circuits in industrial automation environments. This module acts as a reliable interface and galvanic barrier between NAMUR sensors or mechanical contacts located in hazardous areas (Ex-zone) and the standard control systems (PLC/DCS) in the safe area. The device features an intrinsically safe input circuit and dual parallel-controlled relay outputs. The output operation mode (direct/NO or inverse/NC) can be hardware-configured using external terminal jumpers. Housed in a compact IP20 plastic enclosure designed for DIN-rail mounting, it offers a cost-effective and dependable solution for explosion protection.

Specifications:

• Number of channels: 1

• Supply voltage: 20–28 VDC (24 VDC nominal) with less than 10% ripple

• Power consumption: Less than 3.6 W

• Input signal type: NAMUR sensors (DIN 19234) or mechanical dry contacts

• Nominal input parameters: 8.0 V / 8.0 mA

• Switching threshold: 1.55 mA

• Output type: 2 parallel-controlled relays with changeover contacts (SPDT / DPDT)

• Maximum output switching voltage: 250 VAC / 60 VDC

• Maximum contact current: 4 A per output

• Maximum switching capacity: 1000 VA / 60 W

• Galvanic isolation: 2.5 kVrms test voltage between hazardous and safe zones

• Enclosure protection rating: IP20

• Operating temperature range: -25 to +60 °C

• Electrical connection: Removable 8-pole terminal blocks with screw clamps

Application: This switching amplifier is widely utilized in process automation within the chemical, oil and gas, petrochemical, pharmaceutical, and food processing industries. It is designed to safely process discrete signals from inductive or capacitive NAMUR proximity sensors, limit switches, reed switches, and pushbuttons installed in potentially explosive gas or dust atmospheres (ATEX EEx ia IIC/IIB classification), ensuring hazard-free data transmission to programmable logic controllers.
