Yaskawa CIMR-VZBA0010BAA (VZAB1P5BAA) AC Drive – 1.5kW / 2.2kW Inverter

Description:
The Yaskawa CIMR-VZBA0010BAA, also known as model VZAB1P5BAA, is a high-performance AC inverter drive designed for precision motor control in industrial automation. Belonging to Yaskawa’s reliable VZ series, this compact and efficient drive offers excellent torque control, smooth acceleration, and superior energy efficiency. It is built for applications that require precise speed regulation, stability, and protection in demanding environments.

Technical Specifications:

• Model: CIMR-VZBA0010BAA / VZAB1P5BAA

• Manufacturer: Yaskawa Electric Corporation

• Power Rating: 1.5 kW (Normal Duty) / 2.2 kW (Heavy Duty)

• Input Voltage: 200–240 V AC

• Input Phase: 3-phase

• Output Voltage: 0–240 V AC

• Output Current: 7.0 A

• Frequency Range: 0–400 Hz

• Control Method: V/f Control, Open-loop Vector Control

• Overload Capacity: 150% for 60 seconds

• Motor Compatibility: Induction and permanent magnet motors

• Display: Digital keypad with multi-function parameters

• Communication Interface: RS-485 (Modbus RTU)

• Protection Features: Overvoltage, undervoltage, overcurrent, motor overload, short circuit, and overtemperature protection

• Enclosure Rating: IP20

• Cooling Method: Forced air cooling

• Ambient Temperature: –10°C to +50°C

• Dimensions: Approx. 150 × 80 × 160 mm

• Weight: Approx. 1.5 kg

Key Features:

• Compact and lightweight design with easy installation

• High efficiency and low harmonic distortion

• Built-in braking transistor for dynamic motor deceleration

• Energy-saving operation with automatic torque control

• Advanced diagnostics and protection functions

• Suitable for continuous industrial operation

• Compliance with international standards (CE, UL, cUL)

Typical Applications:

• Pumps and fans

• Conveyor and material handling systems

• Packaging and textile machinery

• HVAC systems

• General automation and motion control




  On this page you will find the user manual for Yaskawa V1000 Series. Get detailed technical specifications, installation and operating instructions to ensure optimum performance and reliability.

  Manual for Yaskawa V1000 Series
