Baumer GM400.E14 Absolute Encoder Draw Wire 461907 10-30V SSI w /Cable & Mount NOS

Baumer IVO GM400.E14 SSI Absolute Encoder Draw Wire 461907 150 mm/Umdr.

Condition: The unit was removed from a working environment and is guaranteed to be functional.

Description:

✨ Item Overview

This listing is for a high-precision Draw-Wire Absolute Encoder (also known as a Seilzug or Cable Transducer) manufactured by Baumer IVO in Germany. This unit is ideal for precise linear position measurement in industrial automation, machinery, and various measuring applications.

 Key Specifications:

Manufacturer: Baumer IVO (Made in Germany)

Linear Measurement per Revolution (Seilzug): 150 mm/Umdr. (150 mm per revolution)

Encoder Model: GM400.E14

Part Number (Encoder): 461907 (Matches the draw-wire unit)

Supply Voltage: 10-30 VDC (5%RW - Reverse Voltage Protection)

Resolution: 8192 x 4096 (Singleturn x Multiturn, resulting in 25 bits total resolution)

Interface: Gray SSI (Synchronous Serial Interface)

⚙️ Features & Application

Type: Absolute Multiturn Encoder with Draw-Wire Mechanism

Function: Measures linear distance by extracting and retracting the stainless steel cable.

Output: Provides a unique absolute position value via the SSI interface.

Robust Design: Built for industrial environments.

Connection: Permanently attached gray cable with open ends (as shown in photos).

What is Included

1x Baumer IVO Draw-Wire Absolute Encoder Unit (GM400.E14 / Seilzug 461907)

Integrated connection cable (as pictured)

On this page you will find the user manual for Baumer GM400. Get detailed technical specifications, installation and operating instructions to ensure optimum performance and reliability.

Manual for Baumer GM400
