Bonfiglioli W63 1/10 Worm Gear Motor with 0.55 kW ABB Electric Motor

Bonfiglioli W63 1/10 Worm Gear Motor with 0.55 kW ABB Electric Motor

Product Description: Industrial-grade single-stage worm gear motor assembly, combining a premium-quality Italian-made Bonfiglioli W-series worm reducer and a highly reliable three-phase asynchronous electric motor from the renowned European brand ABB. This heavy-duty unit is engineered to modify output torque and rotational speed across a wide range of industrial machinery. Due to its compact housing design, exceptionally smooth operation, and top-tier component durability, this integrated drive solution ensures an extended service life and consistent performance under rigorous duty cycles. The reducer chassis is manufactured from a robust aluminum alloy, providing excellent thermal dissipation properties.

Specifications:

• Gearbox Manufacturer: Bonfiglioli (Italy)

• Gearbox Series/Model: W63 (W 63 L1 U)

• Gear Ratio: 1:10 (1/10)

• Gearbox Part Number: KG2001060 / O/P SUB ASSY W63 1/10

• Motor Manufacturer: ABB

• Motor Type/Model: M3AAC 71 C 4 (M3AA Series)

• Motor Product Code: 3GAA072003-CSE

• Motor Power Supply Type: Three-phase asynchronous (3-phase induction)

• Motor Power Rating: 0.55 kW (0.55 kW)

• Motor Pole Count: 4-pole

• Motor Speed at 50 Hz: 1355 r/min (rpm)

• Motor Speed at 60 Hz: 1685 r/min (rpm)

• Operating Voltage at 50 Hz: 230 V (Delta - Δ) / 400 V (Star - Y)

• Operating Voltage at 60 Hz: 460 V (Star - Y)

• Rated Current at 50 Hz: 2.7 A (for 230 V) / 1.56 A (for 400 V)

• Rated Current at 60 Hz: 1.3 A

• Power Factor (Cos φ) at 50 Hz: 0.75

• Power Factor (Cos φ) at 60 Hz: 0.71

• Motor Protection Class: IP55

• Motor Weight: 6.5 kg

• Motor Bearings: 6203-2Z/C3 (Drive End), 6202-2Z/C3 (Non-Drive End)

• Additional Motor Protection: Integrated bimetal thermal detectors, type NCC (Opening temp 150°C ± 5°C, Closing temp 120°C ± 15°C)

Application: This worm gear motor is widely utilized in industrial automation systems, packaging lines, and material handling applications. It is ideally suited for belt and roller conveyors, industrial transporters, liquid and moderate-viscosity mixers, dosing systems, light-duty lifting mechanisms, commercial gate drives, as well as ventilation and pumping systems requiring quiet operation, space-saving dimensions, and high reliability under continuous or reversing loads.
